1. Anodizing tank setup: The electrolytic cell is responsible for the entire electrolysis process and it is where the aluminum and cathode are immersed in the electrolytic cell. The electrolytic cell is usually made of chemically resistant materials such as polypropylene, PVC or coated stainless steel. To fix the anodes, the electrolytic cell comprises a rack mechanism which is further connected to the electrical busbar for a uniform and controllable power supply. On the other hand, a separate fixture holds the cathode and is connected to the busbar. During the anodizing tank setup, you need to consider different factors; the size of the tank, the busbar capacity and its safe connection to the rack, the cathode to anode area ratio (1:1 or 1:3), the filtration of electrolyte impurities, etc.

2. Control of acidic solution: The temperature and concentration of the acidic solution directly affect the thickness and quality of the anodized layer. High acid concentration may lead to faster layer growth, but will result in a rougher or burned surface. Therefore, you need to monitor the pH value of the solution. If any changes occur, you can add buffer solution or neutralizing solution according to the standard pH value set for the process.

3. Manage anodized layer and thickness: The anodized layer is formed when oxygen ions in the electrolyte migrate to the metal surface and react with metal atoms. Therefore, layer growth and thickness fundamentally depend on factors that affect the metal and oxygen ion concentrations. For example, temperature, current density, time, acid concentration, etc. Therefore, you must set all processing parameters taking into account thickness requirements and other surface finish characteristics.

4. Anodizing Tank Maintenance: As anodizing progresses, the bath begins to accumulate impurities such as metal salt residues and dissolved chemicals. In addition, metal ion concentrations tend to be higher than standard levels (ideally less than 20 g/L). These impurities affect process efficiency and overall quality. Therefore, filtering impurities and maintaining pH, proper agitation, and ion concentration are critical.

1. Preparation and cleaning: A uniform and smooth surface is essential for the application of the anodized layer. You can achieve this through mechanical treatment and chemical cleaning. Mechanical surface treatment such as grinding and polishing that remove surface irregularities and defects. While alkaline or acid cleaning removes grease, oil, dirt and any other contaminants, followed by rinsing with deionized water to remove residual cleaning agents. Therefore, etching can be further cleaned to peel off the thin surface layer and create a uniform matte effect.

2. Electrochemical process: The part to be anodized next becomes the anode, and the other highly conductive metal becomes the cathode, and both are immersed in the electrolytic cell. When current flows through this electrolytic device, the anode oxidizes and loses electrons. During the electrolysis process, the metal surface is oxidized to form a dense oxide film. This oxide film is very hard and can protect the metal from further corrosion.

3. Coloring (optional): After the oxide film is formed, it can be dyed to give the metal surface a different color.

4. Sealing: The corrosion resistance and wear resistance of the oxide film can be further enhanced by sealing.

Anodizing is a surface treatment method that forms a thin protective oxide layer on the surface of the substrate through an electrochemical process to achieve a smooth and uniform surface treatment, with a roughness value (Ra) as low as 0.5µm. Anodizing can improve the firmness, corrosion resistance, wear resistance and aesthetics of aluminum alloy, magnesium alloy and titanium alloy accessories.

Anodizing has a wide range of applications and is widely used in various industries such as medical devices, electronic communications, automotive accessories, aerospace, agricultural machinery, etc.

1000:1050,1070 Aluminio

Propiedades:Aluminio de alta pureza, conductividad eléctrica, conductividad térmica, resistencia a la corrosión.

Aplicación: Materiales conductores, dispositivos de intercambio de calor, tuberías de equipos químicos.

2000:2011, 2014, 2017, 2117, 2024 Aluminio

Propiedades:Excelente maquinabilidad, alta resistencia, baja resistencia a la corrosión.

Aplicación: Duraluminio es un término general para materiales de corte, materiales estructurales como piezas y tornillos, materiales aeronáuticos, materiales de forja, piezas hidráulicas de automóviles y motocicletas y artículos deportivos.

3000:3003, 3203 Aluminio

Propiedades: Mejor resistencia al calor que el aluminio puro, alta resistencia, buena resistencia a la corrosión.

Aplicación: Tuberías de equipos químicos, equipos de intercambio de calor, cilindros fotosensibles para fotocopiadoras.

4000:4032 Aluminio

Propiedades:Buena resistencia al calor y al desgaste.

Aplicación: Cabezal magnético de VCR, componentes de pistón, forja.

5000:5052,5056 Aluminio

Propiedades:Resistencia media, resistencia a la corrosión, buena capacidad de soldadura.

Aplicación: Tuberías de la industria química, piezas de máquinas, cuerpos de lentes de cámaras.

Aluminio 6001

Propiedades:Aluminio estructural de resistencia media

Aleación con excelente resistencia a la corrosión, soldabilidad y buena procesabilidad.

Aplicación: Vehículos, barcos, equipos de transporte marítimo, materiales de carretera y materiales de construcción, equipos deportivos, etc.

Aluminio 6003

Propiedades: Resistencia a la corrosión, buen tratamiento superficial, excelentes propiedades de extrusión para la mayoría de los materiales extruidos.

Aplicación: Materiales de construcción, materiales de construcción, materiales decorativos, materiales para electrodomésticos y otros productos generales.

7003 Aluminio

Aleación de aluminio estructural de resistencia media para soldar piezas de vehículos, automóviles y locomotoras.

7005 Aluminio

Propiedades:Super duraluminio, la aleación de mayor resistencia, resistente a la corrosión, material soldable de alta resistencia.

Aplicación: Aeronaves y otras piezas mecánicas, equipos deportivos, etc.

9000 Aluminio

Las aleaciones de aluminio de alto rendimiento, con la adición de elementos especiales (como elementos de tierras raras, etc.), tienen un rendimiento excelente o ciertas propiedades especiales.
